    Packaging Machinery Load Cell

    Rudrra Sensor is skilled at manufacturing exclusive range of Packaging Machinery Load Cell (RSL 60051). Engineered with the use of ultra-advanced equipments, the premium load cell is widely used in packing machine applications.

    Made with universally-accepted alloy steel raw materials, it is known for being supremely compact. The rigid construction and latest features coupled with industry-first design make the standard load cell highly efficient.

    Prepared as ISO standards, the modern packaging machinery load cell comes in various models. Modified solutions are also available based on particular specification.

    Despite being advanced having lateral technologies, it doesn’t consume much power. In addition, it requires minimal maintenance. The experienced engineers ensure the product passes the quality test at every stage of production. Through constant supervisions made on enhancing the quality of the products, the noted supplier & exporter of dominant load cells endeavor to produce nothing less than the very best products.

  • Applications

    • Checking weighing scales
    • Hopper scales as well as net weighing
    • Batching plant
    • Construction machineries
  • Diagram

    Packaging Machinery Load Cell - diagram


    Packaging Machinery Load Cell - dimensions

  • Features

    • Universally-accepted alloy steel raw materials
    • Moment-compensated design
    • Rigid construction
    • Industry first design
    • Low maintenance
    • Less power consumption
  • Dimenstions

    Related Load (kg.) 11.25, 22.5 , 45
    Precision C3 Insulation Resistance(MΩ) ≥20000(100VDC)
    Composition Error 0.02 Excitation Voltage (V)9~12 (DC)
    Rated Output (mv/v) 2.00±2% Compensated temp. Range (°C)-10~+40
    Non-Linearity (%FS)0.017 Use Temp. Range (°C) -35~+65 °C
    Hysteresis (%FS)0.02 Temp. Effect on Zero (%FS/10°C)0.0017
    Repeatability (%FS)0.01 Temp. Effect on Span (%FS/10°C)0.014
    Creep (%FS/30min)0.02 Safe Overload (%FS)120
    Zero Balance (%FS)±2 Ultimate Overload (%FS)150
    Input Resistance (Ω)395±5 Defend GradeIP67
    Output Resistance (Ω) 350± 2 Cable6mm,5.0Mtr
